The laser roughen technology is to preheat and strengthen the roll surface by using a high-energy, high repetition rate pulsed laser beam after focusing the negative defocusing light, and form a micro molten pool when the focused focus hits the roll surface.
Please send your inquiry to Email: joy@dumanlaser.com
Item NO. :
DMR-300Payment :
L/C D/A D/P T/T Western UnionProduct Origin :
ChinaShipping Port :
XiamenLead Time :
15 daysPortable Handheld Laser Roughening Machine
The laser texturing machine uses hand-held optical fiber to replace the fixed optical path, which is flexible and convenient. It overcomes the limitation of the workspace, can realize the texturing of various metal surfaces, and can replace sand blasting texturing or shot blasting texturing. It is a new generation of texturing technology.
The laser texturing technology is to preheat and strengthen the roll surface by using a high-energy, high repetition rate pulsed laser beam after focusing the negative defocusing light, and form a micro molten pool when the focused focus hits the roll surface. At the same time, the side blowing device applies auxiliary gas of set pressure and flow to the micro molten pool, so that the molten substances in the molten pool can be stacked to the edge of the molten pool as much as possible according to the specified requirements to form an arc boss (peak number).
The small pits on the surface of the laser textured steel plate are not connected, which is conducive to oil storage and capture of metal debris during the later stamping forming. The oil storage property is good, to prevent stamping scratches, and to ensure the deep drawing property of the steel plate. And the surface of the stamping parts is smooth, and the stamping oil is reduced at the same time.
The laser texturing morphology of the roll surface is uniform and controllable, and the smooth surface accounts for 60% of the whole texturing surface, so that the flatness of the rolled steel plate is high, and the smoothness of the strip steel surface and the freshness after painting are improved. It increases the competitiveness of products for users, and can produce laser mirror steel.
The laser texturing machine can be used for single fiber head or multiple fiber heads. The laser spot energy distribution is uniform, and it has a good spot required for texturing characteristics. It can adapt to various complex texturing, texturing of various devices, and can be organically combined with the manipulator, so texturing is more flexible and convenient. Laser texturing machine is widely used in aviation, aerospace, shipbuilding, weapons, electronic components, sensors, precision machinery and other industries because it is suitable for surface texturing of stainless steel, titanium alloy, aluminum alloy and other materials.
Specificaiton
|
Equipments date |
Laser roughen system |
||
|
Equipment model |
RM-0100 |
RM-0300 |
RM-0500 |
|
Wave length |
1064nm |
||
|
Average power |
100W |
300W |
500W |
|
Power adjust |
10%-100% |
||
|
Laser type |
fibre-detector coupling |
||
|
Laser life |
50,000-60,000 hours |
||
|
Laser class |
IIII level |
||
|
Cable length |
3/5 meters optical fiber |
||
|
Laser transmission |
Scanner Lenses |
||
|
Texturing roughness |
0.5-100 um |
||
|
Texturing size |
50-120 um |
||
|
Software system |
human-computer interface |
||
|
Environmental temp |
5-40 ℃ |
||
|
Environmental humidity |
10-95 % |
||
|
Cooling method |
Air cooling |
Water cooling |
|
|
Equipment voltage |
220V+- 10% |
||
|
Equipment capacity |
1000W |
3000W |
5000W |
|
Equipment weight |
140 KG |
240KG |
320KG |
