Dual-station Track-type Plastic Laser Welding Machine for Welding of Complex Shapes And Irregular 3D Parts


It is suitable for plastic auto parts, plastic medical equipment, plastic casings of electronic and electrical products, lighting products, etc. It is especially suitable for the welding of sensors and electronic component casings that require reliable sealing.


Please send your inquiry to Email: joy@dumanlaser.com

  • Item NO. :

    DMWP-D200W
  • Payment :

    L/C D/A D/P T/T Western Union
  • Product Origin :

    China
  • Shipping Port :

    Xiamen
  • Lead Time :

    15 days

Dual-station Track-type Plastic Laser Welding Machine for Welding of Complex Shapes And Irregular 3D Parts


The dual-station track-type plastic laser welding machine is used for welding products with complex shapes and irregular 3D parts. It adopts dual-station operation and alternate processing of dual-station, which effectively improves production efficiency; it conforms to the international standard fully enclosed laser radiation protection and the integrated design of machine, electricity, water and gas; it has the functions of continuous track teaching and remote control; it can be attached with the same Shaft temperature control system to reliably identify any anomalies in the welding wire and welding temperature; no resin degradation and little debris generation during welding. The equipment is mainly composed of 100W-201W fiber-coupled output semiconductor laser, special laser welding head, eight-axis motion control software, divider, and three-axis robot module.



Suitable for plastic auto parts, plastic medical equipment, plastic casings of electronic and electrical products, lighting products, etc. It is especially suitable for the welding of sensors and electronic component casings that require reliable sealing. Suitable materials: suitable for ABS, PP, PE, PA, PC, PS, PVC, PBT, POM, PET, PMMA and other thermoplastic materials and various modified engineering plastics.



Features

1. The welding area only has a very shallow weld, which requires a peripheral motion system, and the welding area has a beautiful appearance;

2. Good at welding products with complex shapes, irregular 3D parts welding, and can theoretically weld workpieces of any size;

3. Adopt double-station operation, double-station alternate processing, effectively improve production efficiency;

4. There is no resin degradation and almost no debris during the welding process. It can be used directly after welding without cleaning;

5. Optional welding temperature monitoring components, accurate welding temperature control, to ensure the welding pass rate.



Specification

Laser

100w-200w semiconductor laser

Laser wavelength

915nm / 976nm

Focusing spot

Beam circularity

Welding line width

0.5-3.0mm

Motion mechanism

special five axis machine tool

Working stroke

XYZ axis < 200mm * 100mm * 80mm; U-axis 360 (can be customized as required)

Positioning accuracy

XYZ < 0.05mm; U axis < 0.1

Movement speed

XYZ axis: 100mm / S; U-axis 100RPM

Cooling mode

air cooling

Control mode

industrial computer + hl8 axis motion control system, NC model, teaching, graphic file

Optional welding quality monitoring

Temperature monitoring assembly


Samples
