CO2 Laser Engraving Machine 30W 50W for Ceramic Wooden Acrylic Epoxy Laser Marking


CO2 Laser marking machine is widely used in craft gifts, plexiglass, garment leather, wood and paper, food packaging, electronic components, PCB, flexible circuit boards, ceramic substrates, semiconductor, crystal glass, plastic connectors, silicone rubber keys, SMD components and graphic marking on various materials.

Email: joy@dumanlaser.com

  • Item NO. :

    DM-C30W
  • Payment :

    L/C D/A D/P T/T Western Union
  • Product Origin :

    China
  • Shipping Port :

    Xiamen
  • Lead Time :

    15 days

CO2 Laser Engraving Machine 30W 50W for Ceramic Wooden Acrylic Epoxy Laser Marking


The CO2 laser marking machine is controlled by a computer. It uses a 10.6um laser beam to expand, focus, and then control the deflection of the galvanometer to act on the working surface according to a predetermined trajectory, so that the working surface is vaporized to achieve the engraving effect.
It adopts radio frequency metal tube laser, with good beam pattern, stable system performance and maintenance-free, suitable for industrial processing sites of large-scale, multi-variety, high-speed continuous production.
The whole machine is integrated and controlled by one-button switch, which is suitable for online operation.

Application industry
Ceramics, polyvinyl chloride (PVC), ABS, acrylic, epoxy resin, glass, wood, paper, etc., used in wood, craft gifts, electronic components, clothing, leather, paper, food, packaging and other industries, clothing leather.

Features:
1. Using CO2 laser, the beam quality is good, the light output is stable, and the failure rate is low.
2. The high-speed scanning galvanometer cooperates with the servo motor with good performance, and the marking speed is fast and the precision is high.
3. The industrial control computer has strong anti-interference ability and can work stably for a long time in the industrial environment.
4. Multi-function, friendly interface control software, easy to master and improve work efficiency.
5. Reasonable overall structure design, good stability.


Technical specification

Model

DM-C30W

DM-C50W

Laser power

30W

50W

Wavelength

10.6um

10.6um

Laser repetition rate

≤100KHz

≤100KHz

Marker type

Dynamic marking/static marking

Dynamic marking /static marking

Marking scope

110mm×110mm

150mm×150mm

Optional scope

150mm×150mm 250mm×250mm

200mm×200mm 300mm×300mm

Engraving depth

≤5mm

≤7mm

Marking speed

≤7000mm/s

≤7000mm/s

Min.line width

0.10mm

0.15mm

Min. Character

0.30mm

0.40mm

Repeated accuracy

±0.01mm

±0.01mm

Laser

Radio frequency metal tube

Radio frequency metal tube

System operation

WindowsXP/7

WindowsXP/7

Cooling

Air cooling

Water cooling

Power consumption

1.2KW

2.0KW

Power supply

220V/ single phase/50Hz/10A

220V/ single phase/50Hz/15A

CO2 laser marking machine can be equipped with rotating table and automatic supporting system, laser optional 10W, 30W, 50W, 100W, etc..
